EPSON DX4 ECO-SOLVENT COMPATIBLE WITH ROLAND SJ/XC/SC/SP
Digital Printhead, Epson Printhead, Mimaki Printer Spare Parts, Mimaki Printhead, Printer Spare Parts, Roland Printer Spare Parts, Roland Printhead
EPSON DX4 ECO-SOLVENT COMPATIBLE WITH ROLAND SJ/XC/SC/SP
The Epson DX4 printhead has a native resolution of 360 dpi, 2 nozzle lines (corresponding with 2 independent ink channels) and 180 nozzles per line.
The Epson DX4 (fourth generation micro-piezo printhead) has a typical firing frequency of 8 kHz, a minimum droplet size of 3,5 pico litre and is used for either 1 colour through both channels or 2 colours through the independent channels.
This print head is a brand new Epson solvent print head. It is made in Japan and in a Roland Package. It includes the head code for Roland Solvent printers. It does not include the codes for Mimaki or Mutoh printers. Users of these printers have used their existing codes without any trouble. This includes the solvent resistant inlet and seals which are necessary for solvent printers. If you are using a water based printer, select the Epson DX4 waterbased printhead. Printer parts are sensitive items and there are many factors that go into installing them properly.
SKU: PT-EP-DX4
Konica Printhead
KONICA MINOLTA 1024-6PL SHB (3688H)PRINT HEAD KONICA MINOLTA FOR UV PRINTERS
The Konica Minolta KM1024 SH print head is a robust, shear mode, a piezo on-demand printhead that is usable in both binary and 8 level grayscale mode
Providing variable drop size and higher print quality without the use of additional print heads.
The Konica Minolta KM1024 SH print head is a vast improvement over the KM512 print head series,
SKU: PT-KM1024-SHB-6PL
Digital Printhead, Konica Printhead
Konica KM1024 MHB 14PL UV Printhead
The Konica Minolta KM1024 MH print head is a robust, shear mode
Piezo on-demand printhead that is usable in both binary and 8 level grayscale mode
Providing variable drop size and higher print quality without the use of additional print heads.
The Konica Minolta KM1024 MH print head is a vast improvement over the KM512 print head series,
SKU: PT-KM1024-MHB-14PL
Seiko Printhead
Seiko SPT-510 35pl Printhead RH1513D-3322
Compatible Ink: Oil / UV / Solvent● Number of Active Nozzles: 510● Nozzle Pitch: 141.1[um] (Approx.1/180 [inch])● Active Printing Width: Approx. 71.8 [mm]
● Native resolution: 180 dpi
● Jetting Frequency: 7 [kHz] (depending on ink and ink system)
● Drop Volume: 35 [pl] and 80 [pl] versions available
● Driving Interface: Parallel Interface
● Dimensions (W*H*D): 126,3 x 99,2 x 32,9 [mm]
● Dry Weight: 200 [g]
SKU: PT-SPT-510-35PL
Digital Printhead, Kyocera Printhead
KYOCERA KJ4A-0300 INKJET PRINTHEAD 300Dpi – 30kHz – For UV ink
-12%
Digital Printhead, Kyocera Printhead
KYOCERA KJ4A-0300 INKJET PRINTHEAD 300Dpi – 30kHz – For UV ink
This new generation Kyocera KJ4A-0300 is designed for high speed single-pass applications with printers using aqueous ink.
It is a 300dpi two colours printhead with a maximum drive frequency of 30kHz.
It delivers high quality with a small drop volume of 4pl at 158 m/min by making use of 2,656 nozzles arranged across 112.35 mm wide print swath
SKU: PT-KY-KJ4A-0300
Epson Printer Spare Parts, Epson Printhead
EPSON DX5-F186000 ECO-SOLVENT UNLOCK PRINTHEAD
Technology: Micro-Piezo
Native resolution: 1440 dpi
Min. droplet size: 1.5 picolitre
Max. droplet size: 21 picolitre
Tot. amount of nozzles: 1440 (8 lines x 180 nozzles)
Firing frequency: 8 kHz
Ink compatibility: solvent and Eco-solvent based
SKU: PT-EP-F186000
Konica Printhead
KONICA KM512 LN 42PL
The Konica Minolta KM512 LN printhead is a robust print head , shear mode, piezo on-demand printhead that is usable in binary mode only.
The Konica Minolta KM512 LN printhead has 512 nozzles with a droplet size of 42 pico litre and a native resolution of 360 dpi.
It is compatible with oil based, solvent and UV inks. This printhead is also known as the Konica Minolta KM512 LNX.
This is Konica original print head and it includes the Head ID and the necessary waveform information. It carries a product warranty.
SKU: PT-KM512-LN-42PL
Digital Printhead, Ricoh Printhead
Ricoh-MH5420 GEN5 Printhead Water/UV/Solvent
This GEN5 UV printhead is suitable for a range of UV and Solvent printers.
It supports up to four colours and has a total of 1.280 nozzles.
It is built with longevity and robustness in mind and used in the latest industrial inkjet printers.
This is Ricoh original printhead part (number MH5420) and it is covered by a manufacturer warranty.
This Ricoh GEN5 is available in two different cable lengths (connector not included): 140mm or 390mm.
SKU: PT-RC-GEN5-MH5420
Konica Printhead
KONICA KM1024 MNB 14PL OIL & SOLVENT
The Konica Minolta KM1024 MNB print head is a robust, shear mode, piezo on-demand print head that is usable in both binary and 8 level greyscale mode
Providing variable drop size and higher print quality without the use of additional print heads.
SKU: PT-KM1024-MNB-14PL
Digital Printhead, Konica Printhead
KONICA MINOLTA 512MN -WITHOUT HEATER
The Konica Minolta KM512 MN printhead is a robust, shear mode, a piezo on-demand printhead that is usable in both binary and 4 level greyscale mode
It providing variable drop size and higher print quality without the use of additional printheads.
The Konica Minolta KM512 MN printhead has 512 nozzles with a droplet size of 14 picoliters and a native resolution of 360 dpi.
It is compatible with oil-based, solvent and UV inks.
SKU: PT-KM512-MN
Seiko Printhead
Seiko U508GS 12PL Print Head
This 508GS 12PL solvent printhead is suitable for a range of printers, including Infiniti printers.
The 508GS is a state of the art grayscale print head with a built-in damper assembly and a nozzle guard.
This is the original part (number IRH2533U-2410)
SKU: PT-SPT-508GS-12PL
Digital Printhead, Epson Printhead, Printer Spare Parts
Original F192040 DX8 DX10 TX800 PrintHead UV Printhead For Epson TX800 TX710W TX720 TX820 X820 TX830 TX700 TX710W TX720W TX800F
Digital Printhead, Epson Printhead, Printer Spare Parts
Original F192040 DX8 DX10 TX800 PrintHead UV Printhead For Epson TX800 TX710W TX720 TX820 X820 TX830 TX700 TX710W TX720W TX800F
This printhead is modified from the original TX800 printhead. change the adapter part into a new design that can connect 6 pcs ink damper directly. to assemble with some Chinese brand UV printer, eco-solvent printer….etc.
It is a brand new Epson printhead, only takes off the original adapter.
if you need tx800 printhead to install it on the original Epson printer. please tell us before you place an order.
SKU: PT-EP-F192040
FuJiFilm Dimatix Printhead, Starfire Printhead
STARFIRE™ SG1024/SA 10PL PRINTHEAD
Incorporate VersaDrop™ binary and grayscale jetting
Continuous ink recirculation with RediJet™
Two colors operation
Print Width: 64.96 mm [2.55 in.]
Nominal Drop Size: 30 picoliter
Adj. The range for Droplet Size: 30 to 80 picoliter
SKU: PT-SF-SG1024-SA
Epson Printhead, Mutoh Printhead
ORIGINAL MUTOH VJ-1604 PRINT HEAD ASSY – DF-49684
The original VJ-1604 printhead is suitable for the Mutoh ValueJet printer series.
The VJ-1604 printhead has a native resolution of 1440dpi, 8 nozzle lines (corresponding with 8 independent ink channels) and 180 nozzles per line.
The VJ-1604 printhead is either used in 4-colours (2 channels per colour) and has a minimum, variable droplet size of 1.5 pico litre (max. droplet size is 21 pico litre). The typical firing frequency for this print head is 8 kHz.
This VJ-1604 printhead is suitable for Mutoh ValueJet printer series printers.
Mutoh part number for this print head is DF-49684.
SKU: PT-EP-MT-DX5
