KONICA KM1024i MAE-C 13PL Printhead

Original Water Based Konica KM1024i MAE-C 13PL PRH-KON-017 Print Head

The Konica Minolta KM1024i MAE-C printhead is a robust, shear mode, piezo on-demand printhead featuring an All-nozzle Independent Drive System with a Multi-line Structure. In contrast with the existing 3-cycle system drive, an independent drive system that enables simultaneous emission from all 1024 nozzles has been adopted. The high-density structure featuring 4 lines of 256 nozzles aligned with high precision enhances positioning accuracy to realize high-definition print quality. The Konica Minolta KM1024i MAE-C printhead offers a Maximum Drive Frequency of 27kHz, which makes it the ideal inkjet printhead for development of single-pass system inkjet printers capable of high-speed printing.

Used for

Anapurna M2500i,

Anapurna M3200i

Allwin: S320UV

Human Digital Technology
QP-Jet

Konica
Nassenger Pro 120

Technology: Piezo Drop On-Demand
• Native Resolution: 360 dpi
• Cal. Droplet Size: 13 pico litre
• Max. Drops in Greyscale: 8 drops
• Tot. Amount of Nozzles: 1024 (256 nozzles per line)
• Print Width: 72 mm
• Firing Frequency: 27 kHz
• Ink Compatibility: Water Based Inks
• Dimensions: W131mm x D18mm x H94mm

Suitable for:  Water Based Inkjet Printer.
